IR Transceiver

The IR transceiver module can transmit and receive infrared signals in the 940 nm band.



Real-life examples

  • Air conditioner and its remote control

  • TV set and its remote control

  • Remotely-controlled car and its IR controller

Specifications

  • Dimensions: 24 × 24 (mm)
  • Frequency band: 940 nm
  • Supported protocol: NEC
  • Transmission range: 6 m
  • Receiving range: 6 m
  • Operating current: 40 mA
