mBot Coding Knowledge Card Part 1

未标题-2_001.png未标题-2_002.png未标题-2_003.png未标题-2_004.png未标题-2_005.png未标题-2_006.png未标题-2_007.png未标题-2_008.png未标题-2_009.png未标题-2_010.png未标题-2_011.png未标题-2_012.png未标题-2_013.png未标题-2_014.png未标题-2_015.png未标题-2_016.png未标题-2_017.png未标题-2_018.png未标题-2_019.png未标题-2_020.png未标题-2_021.png未标题-2_022.png未标题-2_023.png未标题-2_024.png

Was this article helpful?
7 out of 7 found this helpful

Comments

2 comments
  • Can i have a download pdf version please?

    0
  • I am having problems getting pass the 5-5 problem in the software. The question is: Tell the mBot to move forward and turn left for 1 second until there is obstacle ahead.

    I have the block keep moving forward at speed of 150.

    wait until obstacle ahead

    turn left 1 second at the speed of 150

    wait until obstacle ahead

    I can't get pass this one, I don't know what is wrong.
